Jelly gummy bear candy making machine

Model No.:SGDQ150 Description: Servo driven deposit Jelly gummy bear candy making machine is an advanced and continuous plant for making high quality jelly candies by using aluminum Teflon coated mould. The whole line consists of jacketed dissolving tank, jelly mass mixing and storage tank, depositor, cooling tunnel, conveyor, sugar or oil coating machine. It is applicable for all kinds of jelly-based material, like gelatin, pectin, carrageenan, acacia gum etc. Automated production not only save time, labor and space, but also reduce the production cost. Electrical heating system is optional.

Model	SGDQ150	SGDQ300	SGDQ450	SGDQ600
Capacity	150kg/h	300kg/h	450kg/h	600kg/h
Candy Weight	as per the candy size
Depositing Speed	45 ～55n/min	45 ～55n/min	45 ～55n/min	45 ～55n/min
Working Condition	Temperature：20～25℃； Humidity：less than 50%
Total power	35Kw/380V	40Kw/380V	45Kw/380V	50Kw/380V
Total Length	18m	18m	18m	18m
Gross Weight	3000kg	4500kg	5000kg	6000kg

Deposit gummy candy making machine： For production of deposited jelly candy, gummy bear, jelly bean etc Production flowchart → Gelatin melting→ Sugar & glucose boiling→ Add melt gelatin into cooled syrup mass → Storage→ Add flavor, color and citric acid→ Depositing→ Cooling→ Demoulding→ Conveying→ drying→ packing→ Final productDeposit jelly candy machine Advantages： 1、Sugar and all other materials can be automatic weighed, transferred and mixed through adjust touch screen. Various kinds of recipes can be programmed in the PLC and applied easily and freely when required. 2、PLC, touch screen and servo driven system are world famous brand, more reliable and stable performance and durable use-life. Multi language program can be designed. 3、Long cooling tunnel increase the production capacity. 4、Silicone mould is more efficient for demoulding.Specification of Jelly gummy candy making machine：
